Key Differentiators
Certifications
RoHS, WEEE, FCC Part 15, ICES-003, CISPR 32, CE Mark Compliant
Features & Benefits
4 x UART (LVTTL), USB, Ethernet & NTRIP Client, 2 x CAN (ISO 11898-2)
Board Connector 28-pin male header (2mm); Samtec PN TMM-114-03-G-D
Discrete Interfaces 1 x PPS Output, 2 x User Event In, Direct Quadrature Encoder Input
GNSS Antenna Connector RF: 2 x MMCX, female, straight, 100mA Maximum Current
Internal Data Storage On-board Micro-SD Card Slot with optional USB access
Dimensions
Weight
<30g
Dimensions
71mm x 45mm x 12mm
Performance Data
Accel Bias In-Run Stability (mg 1σ)
5 μg 1σ
Accel Bias Repeatability (mg 1σ)
500 μg 1σ
Operating Temperature
-40 °C to +85 °C
Usually Bought With
GNSS antennas and cables with Survey and UAV grade options
HGuide Data Reader, SDK and ROS Drivers to support easy integration
HGuide development kit to reduce design time/costs
GNSS Constellations
BeiDou Phase 2&3 B1/B2/B3
GLONASS G1/G2
GPS L1/L2
Galileo E1/E5b
SBAS (WAAS, EGNOS, MSAS, GAGAN,SDCM)
Power Consumption
3 Watts Typical Watt
Supply Voltage
+3.3VDC +/- 4% voltage alternating current
